   "n": "MQTT Data",
   "pa": 7,
   "ps": 0,
   "s":  0.34553,
   "c":  120,
   "a": 7.342432
 },
 {
   "n": "The Juice Factory",
   "pa": 7,
   "ps": 0,
   "s": 0.34553,
   "c": 120,
   "a": 7.342432
 }
]

n - Name of the dataset (String)
pa - Purge Age. Set in Days (Int 32)
ps - Purge Size. Set in Gigs (Int 32)

GET Dataset

GET Dataset
URL http://<yourServerAddressHere>:4511/api/datasets/{dataset}

Returns an object of the configured dataset in the Real Time Historian with its purging rules.

Return Schema:

{
 "n": "The Juice Factory",
 "pa": 7,
 "ps": 0,
 "s": 0.34553,
 "c": 120,
 "a": 7.342432
}

n - Name of the dataset (String)
pa - Purge Age. Set in Days (Int 32)
ps - Purge Size. Set in Gigs (Int 32)

POST Dataset

POST Dataset
URL http://<yourServerAddressHere>:4511/api/datasets/{dataset}

Updates an existing dataset in the Real Time Historian

Request Body:

{
 "n": "The Juice Factory",
 "pa": 14,
 "ps": 0
}

n - Name of the dataset (String) *required
pa - Purge Age. Set in Days (Int 32) *required
ps - Purge Size. Set in Gigs (Int 32) *required

GET Tags

GET Tags

URL http://:4511/api/datasets/{dataset}/tags

Returns an array of tags stored within the particular dataset. Tags will be classified between System generated diagnostics tags and user generated tags in the response.

Each dataset will have "System Tags" and "User Tags". User tags are tags either stored by a collector or inserted by the API. "System Tags" are related to diagnostic information about process specific parameters and dataset activity, like read and write speeds etc. Please see this article explaining System Tags

Optional URL parameter:

contains - Filter criteria for tags to be returned (String)

Return Schema:

{
 "n": "FL001.State",
 "d": "Filler 1 State",
 "u":
 {
  "0": "Idle",
  "10": "Startup",
  "20": "Running",
  "21": "Bottle starvation",
  "22": "Bottle jam",
  "23": "Downstream bottleneck",
  "30": "Cleaning"
 },
 "fl":
 {
  "Measure": "State",
  "Product": "Juice",
  "Area Code": "131",
  "Equipment": "Filler",
  "Equipment Number": "1"
 },
"t": "System.Integer"
}

n - Name of the tag (String)
d - Description of the tag (String)
f - Format of the value (String)
u - Unit of Measure or State Enumeration (dictionary <Int32,String>)
fl- Fields. Metadata associated with a tag (dictionary <String,String>)
t - Data Type of the tag

POST Tags

POST Tags

URL http://:4511/api/datasets/{dataset}/tags

Updates or creates an array of tags stored within the particular dataset. If the dataset does not exist, it will be created automatically.

Request Body:

[
 {
  "n": "string",
  "d": "string",
  "f": "string",
  "u":
  {
   "additionalProp1": "string",
   "additionalProp2": "string",
   "additionalProp3": "string"
  },
  "fl":
  {
   "additionalProp1": "string",
   "additionalProp2": "string",
   "additionalProp3": "string"
  },
 "t": "string"
 }
]

n - Name of the tag (String) *required
d - Description of the tag (String)
f - Format of the value (String)
u - Unit of Measure or State Enumeration (dictionary <Int32,String>)
fl- Fields. Metadata associated with a tag (dictionary <String,String>

POST Tag

POST Tag

URL http://:4511/api/datasets/{dataset}/tags/{tagname}

Updates or creates a tag stored within the particular dataset.

Request Body:

{
 "n": "string",
 "d": "string",
 "f": "string",
 "u":
  {
   "additionalProp1": "string",
   "additionalProp2": "string",
   "additionalProp3": "string"
  },
 "fl":
  {
   "additionalProp1": "string",
   "additionalProp2": "string",
   "additionalProp3": "string"
  },
 "t": "string"
}

n - Name of the tag (String) *required
d - Description of the tag (String)
f - Format of the value (String)
u - Unit of Measure or State Enumeration (dictionary <Int32,String>)
fl- Fields. Metadata associated with a tag (dictionary <String,String>)
t - Data Type of the tag

GET Tag Data

GET Tag Data

URL http://:4511/api/datasets/{dataset}/data/{tagname}

Returns the data from the requested tag as stored in the referenced dataset.

Start and end time can either be supplied in standard ISO notation or UNIX format.

Relative time can also be specified for either start or end times.

If no times are specified in the request, the latest point will be returned.

If no end time is specified, it will default to "now".

Optional URL parameter:

start - Start timestamp to return data. ISO format

end - End timestamp to return data. ISO format

unixStart - Start timestamp to return data. UNIX Format

unixEnd - End timestamp to return data. UNIX Format

relativeStart - Relative start time i.e -2h

relativeEnd - Relative end time i.e -1h

Relative time periods include:

y - Years

M - Months

d - Days

h - Hours

m - Minutes

Return Schema:

{
 "t":
  {
   "n": "Process.Memory",
   "d": "Process memory usage",
   "f": "0.0",
   "u":
    {
     "1": "MB"
    }
  },
 "s": "2024-10-02T16:12:58.716699Z",
 "e": "2024-10-02T16:12:58.716699Z",
 "d":
  [
   {
    "t": "2024-10-02T16:12:53.643451Z",
    "v": 615.0390625,
    "q": 192
   }
  ]
}

t - tag object
s - start time
e - end time
d - TVQ array of data

POST Tag Data

POST Tag Data

URL http://:4511/api/datasets/{dataset}/data/{tagname}

Post array of TVQ values to a tag in a particular dataset.

Request Body:

[
 {
  "t": "2024-10-02T16:16:50.989Z",
  "v": "string",
  "q": 0
 }
]

t - timestamp
v - value
q - quality

POST Dataset Status

POST Dataset Status

URL http://:4511/api/datasets/{dataset}/status

Post a TVQ value to mark the current status of a dataset. To be used to handle loss of comms etc.

Request Body:

[
 {
  "t": "2024-10-02T16:16:50.989Z",
  "v": "string",
  "q": 0
 }
]

t - timestamp
v - value
q - quality

Standard quality codes and values to be used include:

null value and 64 quality, collector's heartbeat has not been detected for 10 seconds, all collector's tags set to Store Forward
null value and 28 quality, collector has shutdown
null value and 24 quality, collector is communicating with the Historian, but the collector has lost communication with its data source
